Change Color Number on a Path with Running Stitches

Change Color Number on a Path with Zig-Zag Stitches

Change Color Number on a Path with E Stitches

Stitch Density on a Path with Zig-Zag Stitches

	Density: 3 stitches / mm		Density: 6 stitches / mm

Stitch Density on a Path with E Stitches

	Density: 0.4 lines / mm		Density: 1.0 lines / mm

Stitch Density on a Path with Longitudinal Stitches

	Density: 2 lines / mm		Density: 4 lines / mm

Stitch Density on an Area Path with Pattern Fill Stitches

	Density: 2 lines / mm		Density: 6 lines / mm

It turns irregular the edges of the object.

Properties:

•Side: Specify the object side where to apply the effect.

•Value: Adjust the width percentage affected by the effect.

	Random Edge Side A value: 40%
	Random Edge Side B value: 15%
	Random Edge Both Sides value: 25%

Define density variation curves in order to obtain effects such as color fades including up to 3 colors.

Assign up to 3 overlapped fills to the same object with different density variation pattern and a different color.

	1-color variable density
	2-colors variable density
	3-colors variable density

Underlay is also known as base layer. It is used to tighten the fabric enough to avoid its deformation when stitching on it. The underlay stitches should remain hidden under the main fill.

You can select the proper type of underlay and its properties according to the fabric / material and the design properties. Underlay types include: centered, edge, zig-zag, parallel, etc.

	Centered Underlay on Path with Zig-Zag Stitches
	Edge Underlay on Path with Zig-Zag Stitches
	Double Zig-Zag Underlay on Path with Zig-Zag Stitches

Correct the fabric shrink effect (caused by several factors, such as the stitch density, the type of fabric, the thread pull, etc) by by enlarging the stitches that tend to shrink when being embroidered. Basically, the stitches are stretched on their ends.

Properties are:

•Side: You can select the side (A, B, Both). Recommended value is Both.

•Type: Fixed or Proportional:

oFixed: You can set a fixed value, independent of the stitch length.

oProportional: This type varies according to the stitch length.

	Fixed type, Value: 0.6 mm		Proportional Type, Value: 15%

Compensate the lack and the heaps of stitches when the stitch direction of Zig-Zag stitches changes noticeably (sharp curves). The program creates intermediate stitches in curves or tight corners to avoid an unnecessary amount up of stitches (in the smaller edge) and spaces (in the larger edge). Intermediate stitches are only created if the object requires it (trigger at threshold).

Properties are:

•Levels: The maximum number of intermediate stitches to create when required.

oLevel Value: Distance of the intermediate stitches, relative (percentage) to the stitch length.

•Layout options: centered or hidden

oCentered: intermediate stitches will be centered between the last and the next stitch.

oHidden: intermediate stitches will be orientated towards the next stitch.

•Trigger at: Set the minimum opening value (larger side / smaller site) to create intermediate stitches.

	Levels: 1, Value: 85%, Trigger: 70%		Levels: 3, Value: 85%, Trigger: 70%

Filter the small stitches of the object (smaller than the indicated value).

Options are:

oAutomatic: The filter is enabled and the minimum stitch length used is the general value set in Options And Preferences.

oUser defined: The system will delete stitches shorter than the indicated value.

Sample of Delete Small Stitches: Path with Running Stitches

Sample of Delete Small Stitches: Column with Zig-Zag Stitches

Internal path or sequence of stitches automatically generated by the program required to travel from one location of the object to another one (connections of regions) while producing the stitches of the object in order to avoid long jumps. Those stitches will be hidden under the main fill.

Available options are:

oCenter Walk: The position of the under is set to the center (for normal density fills).

oEdge Walk: The position of the under is set at a certain distance from the edges (for low density fills).

Properties are:

•Stitch length: Defines the stitch length of the under path. The higher the value, the greater the stitches are apart from each other.

•Edge Distance: Defines the distance of under path to the edge.

Number of stitch or lines that will overlap on 2 adjacent regions of an object.

When the program divides the object in regions to fill with stitches (usually when considering the entry and exit point of the object), the limit between both regions may result in unfilled spaces when sewing the design. This property adds more stitches to avoid or compensate that undesired effect.

The value is generally 1 line, but according to the type of fabric to sew you might have to consider increasing this value.

	Overlap Lines: 1		Overlap Lines: 2

Area close to the border free of stitches. The exclusion margin avoids small stitches near the edges, as they may produce an irregular finishing aspect.

If the width of the object to fill is smaller than the specified value, the pattern is not carried out. Instead, you will get zig-zag stitches in these small areas that will provide a better quality result.

It slightly moves the end of the stitch corresponding to the emboss effect according to the stitch directions. This property avoids accumulating needle penetrations too close which negatively affect the emboss effect.

Insert tack-down stitches to prevent unfixed stitches when connecting far parts of the object.

Types of Lock Stitches are:

oClassic

oStar

oTwist

oCross

oArrow

Properties:

•Length: Specify the lock stitch length for Classic type.

•Scale: change the size of the lock stitch.

•Repetition: Define the number of times to repeat the lock stitch.
